Glue Breaker
Technical advantages：
1. The roller adopts a composite process structure, and the 50mm below the roller surface is a cooling water tank, and the cooling effect of the roller is particularly remarkable.
2. The roller is made of steel, and the surface layer is welded with wear-resistant alloy, which has good welding performance and is convenient for repairing.
3. The equipment has a high degree of automation. It adopts electric pitch adjustment and electric refueling, which is easy to operate.
4. The whole equipment adopts modular structure, which is convenient for maintenance.
5. Due to the advanced composite structure roller, the cooling effect is obvious, the line speed is greatly increased, the output of the single machine is also increased, and the temperature of the produced rubber powder is very low, which greatly improves the product quality.
Glue Breaker
| Technical parameter | |
| Parameters Model | XKP560×550×1000 Glue Breaker |
| Working diameter of front roller(mm) | 550 |
| Working Diameter of Rear Roller(mm) | 560 |
| Working length of roller(mm) | 1000 |
| Front roller linear speed(m/min) | 38.9 |
| Linear speed of rear roller(m/min) | 61.5 |
| Linear speed ratio of front and rear rollers | 1:1.58 |
| Roll surface material | Steel matrix surfacing alloy |
| Cooling method | Peripheral slot cooling |
| Yield | 900±50kg/h |
| Main motor power(KW) | 6-200KW |
| Reducer | ZSY500 square box hard tooth surface reducer |
| Bearing(double structure) | Self-aligning roller bearing |
| Pitch adjustment method | Electric pitch adjustment |
| Lubrication method | Electric dry oil pump |
| Dimensions (length×width×height) | 5430×1930×1725 |
| Machine weight(tons) | ≈21 |
